Monitoring with Traceability
AURA X36 centralizes signal reading, action on outputs, local authentication, and log of interventions. When there is connectivity, it synchronizes events and operations with the AITHA Platform.
Technical Capabilities
Features of the AURA X36 gateway
Input and output monitoring
Reading of digital and analog inputs, current measurement, and control by potential-free relays.
Local event logging
Local storage of events, accesses, and operations in case of connectivity interruptions.
Communication with the AITHA Platform
MQTT over Ethernet, Wi-Fi, or 4G IoT for synchronization with the platform.
Authenticated intervention
Action via mobile app, local Bluetooth connection, and complete log of each intervention.
Inputs and Outputs Specifications
Technical detail of the field interface
| Parameter | Specification |
|---|---|
| Digital inputs | 16, opto-isolated |
| Digital outputs | 8 potential-free relays |
| Relay | 10 A up to 250 Vac |
| Analog channels | 3 inputs 0-10 V and 1 output 0-10 V |
| Current inputs | 2, range 0 to 20 mA |
Communications and Construction
Connectivity and physical specifications
| Parameter | Specification |
|---|---|
| Communications | RS485, RS232, USB, Ethernet, Wi-Fi, Bluetooth, 4G IoT |
| Communication with the AITHA Platform | MQTT over Ethernet, Wi-Fi, or 4G IoT |
| Reference dimensions | 320 x 220 x 100 mm |
| Power supply | 100-240 Vac, 50/60 Hz |
| Operating temperature | -20 °C to +60 °C |
| Environmental protection | IP20, unsealed box for direct outdoors |
| Impact | IK7 |
Monitor Distributed Infrastructure
We analyze signals, communications, local security, and integration requirements to define the scope of AURA X36.
